AXOR Starck Organic2-handle basin mixer 170 for wash bowls with waste set

Art. no. 12012000
Please try again.
Please try again.
Article features
- consists of: 2-handle basin mixer, waste set
- ComfortZone 170
- projection: 116 mm
- spout height: 168 mm
- handle variant: cylinder handle
- spray type: shower spray
- maximum flow rate at 3 bar: 3,5 l/min
- flow rate booster: 5 l/min
- ceramic cartridge for temperature control
- ceramic valve for volume control
- temperature limitation adjustable
- separation of temperature and volume control
- with isolated water conduction - without contact with nickel and lead
- suitable for continuous flow water heaters
- non-closing waste set
- connection type: G ⅜ connections
- connection dimension: DN15
- EU taxonomy: max. 6 l/min - Substantial Contribution (SC) possible
Downloads
Planning data
Technical drawings
Installation information
Information
Please always observe the safety and installation information for your product. You find these details within the assembly instructions.Optional accessories
Spare parts for year of manufacture 11/12
To the spare parts catalogueArt. no. | DescriptionArt. No.Description & Article No. |
---|
a | waste50001000 |
b | fixation extension 35 mm13898000 |
1 | handle98296000 |
2 | handle fixing set98932000 |
3 | color-ring cold / hot water98304000 |
4 | cartridge, assy98303000 |
5 | cramp98403000 |
6 | O-ring 11x1,598385000 |
7 | hollow set screw M5x1698404000 |
8 | shut off cartridge98301000 |
9 | flow limiter (3,5 l/min)98405000 |
10 | spout cpl.98297000 |
11 | spray former98299000 |
12 | flow limiter (5 l/min)95311000 |
13 | aerator M24x1 (7 l/min)98300000 |
14 | special tool95158000 |
15 | flat seal98749000 |
16 | fixing set (Ø 32)13961000 |
17 | connection hose 900 mm M8x0,75 G3/895372000 |
18 | O-ring 7x1,598422000 |
19 | non return valve DW 1096456000 |
20 | filter packing95291000 |
Innovative technologies
Excellent user comfort
Saving resources with pleasure
Less limescale, more joy
ComfortZone
Excellent user comfort
More elbow room when washing hands, a comfortable way to wash hair or just fill containers: The better the tap fits the space, the more flexible the options become. We call the area between the tap and the ceramics the ComfortZone because you can use it however you like.
EcoSmart
Saving resources with pleasure
hansgrohe standard taps are equipped with our EcoSmart technology to save water and energy – since 2010. While enjoying the full water experience, it consumes max. 5 l/min. Good for a conscious consumption of water and energy.
QuickClean
Less limescale, more joy
Who actually likes cleaning? Limescale deposits and dirt disappear in an instant with this technology. Simply rub the flexible silicone discs or nozzles with a finger. It’s fast and keeps cleaning to a minimum.
Five-year manufacturer’s guarantee
5
Year warranty
Always creating the highest quality products defines our approach to design, manufacturing and performance. ‘Made by Hansgrohe’ is your assurance of quality.
